WY400-10N. UHF Base Station 10 elements Yagi Antenna 400-470Mhz, 11.85-14dBi.

ELECTRICAL DATA:

Type: 10 Elements Yagi.

Frequency range: 400-470Mhz.

Impedance: 50Ω.

Radiation (H-Plane) beamwidht @-3dB: 50º.

Radiation (E-Plane) beamwidht @-3dB: 45º.

Front to back ratio: ≥17d8.

Polarization: Linear Vertical or Horizontal.

Gain: 11.85 – 14 dBi.

Max power (CW) @30ºC: 150Watts.

Grounding Protection: All metals parts are DC-grounded, the inner conductor shows a DC short.

Connector: N-Female with rubber protection cap.

MECHANICAL DATA:

Materials: Anodized 6063-T5 Aluminium, EPDM rubber, thermoplastic UV stabilized, Chromed Brass.

Wind Load @ 150km/h: 142N.

Wind Resistance: 120Km/h ; 75mi/h.

Wind Surface: 0.115m² ; 0.23ft².

Dimensions W x H (Approx.): 2000 x 375mm ; 6.6 x 1.2ft.

Turning radius (Approx.): 1860mm ; 6.1ft.

Weight (Approx.): 2040gr ; 4.5lb.

Operating temperature: -40ºC to +60ºC.

Mounting Mast: Ø35-52mm ; Ø1.4 – 2.0in.

Boom / Dipole / Element Diameter: Ø32mm ; 1.3in / Ø 24mm ; 0.95in / Ø12mm ; 0.5in

CONTENT:

x1 WY400-10N. Yagi antenna.
